Aviation Obstruction Lights




Part No. Description Lamp Used
JBI 901 Single Aviation Obstruction Light of incandescent lamp, die-cast aluminum alloy housing with polycarbonate dome. GLS 60 - 100W




Part No. Description Lamp Used
JBI 902 Double Aviation Obstruction Light of incandescent lamp, die-cast aluminum alloy housing with polycarbonate dome. 2 X GLS 60 - 100W




Part No. Description Lamp Used
JBI 903 Single Aviation Obstruction Light of Neon Spiral, with built in 75VA Step up transformer, die-cast aluminum alloy housing, Heat Resistant, Clear thick glass & Accessories. 75 VA Neon Spiral




Part No. Description Lamp Used
JBI 904 LED Double Aviation Obstruction Light, die-cast aluminum alloy housing with Polycarbonate Dome. 2 X LED’s System
Salient Features
  • Gives omni directional light
  • Protection: Weather proof IP 55
  • Material of construction: Cast aluminum (LM 6)
  • Transparent part: Polycarbonate glass Dome
  • Gasket: Neoprene.
  • Light source: High power light emitting diodes, mounted on glass epoxy Fire Retarded PCBs
  • Operates directly on 230V/50Hz ac, can withstand high voltage fluctuations.
  • Multiple light elements reduce chances of complete blackout due to any unlikely lamp failure
  • Approx life of around 100000 hrs
  • No. Of LEDs: 300 nos.
  • Luminous Intensity: 10-35 Cd
  • Earthing Terminal: Provided.
  • Paint: Aviation Yellow (Epoxy Powder Coated)
  • Optional: Flashing / Inbuilt photo sensor for automatic control.




Part No. Description Lamp Used
JBI 905 LED Double Aviation Obstruction Light, die-cast aluminum alloy housing with Polycarbonate Dome. 2 X LED’s System
Salient Features
  • Gives omni directional light
  • Protection: Weather proof IP 55
  • Material of construction: Cast aluminum (LM 6)
  • Transparent part: Polycarbonate RED glass Dome
  • Gasket: Neoprene.
  • Light source: High power light emitting diodes, mounted on glass epoxy PCBs
  • Operates directly on 230V/50Hz ac, can withstand high voltage fluctuations.
  • Multiple light elements reduce chances of complete blackout due to any unlikely lamp failure.
  • Approx life of around 100000 hrs ¨ No. Of LEDs: 600 nos.
  • In an unlikely situation of one complete LED lamp cluster failure the other continues to work.
  • Operates directly on 230V/50Hz ac.
  • Installation by means of a 38 mm E.T. stem.
  • Earthing Terminal: Provided.
  • Paint: Aviation Yellow (Epoxy Powder Coated)
